vertical airflow screen

Airflow screen is a kind of screen screening equipment for fine powder, screen can be replaced arbitrarily.

Air flow: 240-4900

Screen machine power: 3-15KW

Main engine speed: 450-145

Applied Material

Clay, abrasive, aluminum powder, glass powder, refractory materials, etc

Product Description

Material feeding system by entering your hammer crusher, airflow sizing screen flow classification area on a grade, most of the coarse particle is separated, fine powder with a small amount of coarse particle into the turbine classification by the increased flow area on second grade, the fine powder, through the classification into the trap to collect broken stone machine, the coarse particle from the classifier discharge valve discharge.

Features

High screening efficiency: can reach more than 95%

Widely applicable fineness: 80-530 mesh powder materials can be screened

Screen vertical installation, no load, long service life

The screening procedure is carried out under the condition of negative pressure semi-circulation without dust pollution

It can be used with all kinds of grinders and air channels

Low noise, low power consumption, continuous operation

Technical parameters

model	LQS-600	LQS-1000	LQS-1600
gas flow	240-1100	300-2500	460-4900
Screen mesh size	80-600 mesh replacement at will
Into the material particles	40 mesh is fine
Sieve machine power	3	5.5	15
Spindle speed	450-145
Sieve machine outside diameter	φ600	φ1000	φ1600
The whole high	1150	1730	2300

Application

Graphite powder, tree powder, Chinese medicine powder, coating, fly ash, talcum powder, industrial drugs, cosmetics, fire extinguishing agent, plastic powder, clay, abrasive, aluminum powder, glass powder, refractory materials, starch, milk powder, metallurgical powder, electromagnetic materials, copper powder, carbon black, activated carbon, light calcium carbonate, iron ore, etc.
